Max K65S

MAX K65S is very easy to use and very lightweight. As each of our machine, it also has a remote control via a pneumatic valve in lubricator. K65 is very popular in electrical and telecom connections, especially to PE, PCV pipes diameter ø50 mm. As our other machines, K65 has very high precision and speed.

APPLICATION:

Make a hole diameter [mm] ø65
Inserting PE, PCV pipes directly behind the machine [mm] ø50, ø63
Inserting PE, PCV pipes manually with expanding tools [mm] ø25- ø55

Basic set include:

  1. MAX K65S mole,
  2. control power supply hose 20 mb,
  3. Lubricator with control panel,
  4. Set of tools (2 pcs.).
  5. Oil EkoMAX 5l

Specifications

Hammer Outside Diameter Length Weight Air consumption Oper. air pressure
65 mm 1366 mm 22.5 kg 0,8 (1,2) m3/min 7 bar
Impact energy Impact frequency Ordering code
100 J 6 Hz K65S
Max K65S


The most commonly used accessories
