The hand-held pneumatic rock drill VK17-1W is an ultralight-weight pneumatic drill which makes it a winner with confined spaces for operators. The hand-held pneumatic rock drill VK17-1W is used for drilling holes for secondary breaking in blasting operations in quarries, construction works, railways etc
| Weight | Air consumption | Impact energy | Impact frequency | Oper. air pressure |
|---|---|---|---|---|
| 16,5 kg | 2,8 m3min-1 | 30 J | 37 Hz | 0,4 – 0,7 MPa |
| Torque | Number of hits / one turn of drill rod | Length x Width | Air supply hose | Water supply hose |
|---|---|---|---|---|
| 5 Nm | 12 | 542 x 430 mm | Ø 16-20 mm | Ø 13 mm |
| Connecting thread | Effective value of weighted acceleration | Measured sound power level | Guaranteed noise level LWA | Bore Diameter |
|---|---|---|---|---|
| G 3/4'' Quick Coupling | 16,6 m.s-2 | 110.7 dB | 112 dB(A) | 26 – 32 mm |
| Direction of rotation of the drill stem | Bore rod shank | Ordering code |
|---|---|---|
| Vlevo - Left – Влево | #19x108 (3/4x4 ¼”) | 9403-581 |
