VK 10-C (#22x108 )

The VK10, with a T handle, is best for vertical work such as concrete drilling, plug drilling, drilling for smooth blasting and seam drilling, all of which require a drill that is easy to move. Light and easy to handle, VK10 rock drills are ideal for those quick jobs and for working in difficult-to-get-to areas. The ratchet-wheel action provides faster rotation and higher impact frequency for drilling in soft to medium hard rock.

The Right Drill for Your Application.

Benefits of use

  • Light weight
  • Very easy mobility
  • Built in air flushing
  • The VK10-C, with a T handle, is best for vertical
  • Concrete Drilling

Specifications

Vibration level (Hammer) Weight Air consumption Impact energy Impact frequency
14.1 m.s-2 12 kg 1,5 m3min-1 22 J 43 Hz
Oper. air pressure Torque Number of hits / one turn of drill rod Length x Width Air supply hose
(60-90 PSI) 0,4 – 0,63 MPa 4 Nm 12 560 x 430 mm Js 13, Js 16 mm
Connecting thread Guaranteed noise level LWA Bore Diameter Direction of rotation of the drill stem Bore rod shank
G 3/4'' Quick Coupling 112 dB(A) 24 - 34 mm vlevo - links - left #22x108 (7/8x4 1/4”)
Ordering code
9403-690
